PERTICI 500 TSE
Double mitre saw
Special features:
500 TSE is a double mitre saw with controlled axes and saw blade Ø 500 mm. The machine consists of three main parts, a solid electro-welded machine bed on which the stationary sawing unit is mounted and a mobile sawing unit positioned on the machine bed with electronic positioning (X axis). The rotary axes of the two saw heads allow the saw units to be adjusted at an angle of 45° inside and up to 20° outside.
Technical data:
Control unit
Pertici manuell
Cutting range
4.000 - 6.000 mm
Saw blade diameter
500 mm
Version
automatic
Materials
Aluminium
Plastic
Steel
Plastic
Steel
Additional information:
Branches
Facade construction
Window construction
Türenbau
Window construction
Türenbau
Application areas
Aluminium and PVC bar machining
Steel processing
Steel processing
